Generic representation
List price: 16.90 GBP
Available
Package quantity: 10
ISO: CNMU 12 06 16-PR 4425
Material Id: 8019701
EAN: 7323225785907
ANSI: CNMU 444-PR 4425
Start values (KAPR 95 deg )
P2.1.Z.AN, Hardness: 175 HB
P
ap 0.157 in (0.059 - 0.276)
fn 0.02 in/r (0.013 - 0.03)
hex 0.02 in/r (0.013 - 0.03)
vc 920 sfm (1050 - 780)
Technical illustrations
Technical illustrations
Product data
Workpiece material(s)(TMC1ISO)
P
Chip breaker(CBMD)
PR
Operation type
(CTPT)
roughing
Insert mounting style code (metric)(IFS)
Partly cylindrical, 40-60 deg countersink on one or two sides
Fixing hole diameter(D1)
0.1811 in
Insert size and shape
(CUTINT_SIZESHAPE)
CN1206
Cutting edge count(CEDC)
4
Inscribed circle diameter(IC)
0.5 in
Insert shape code(SC)
Rhombic 80
Cutting edge effective length(LE)
0.4447 in
Corner radius
(RE)
0.0625 in
Hand
(HAND)
Neutral
Grade
(GRADE)
4425
Substrate(SUBSTRATE)
HC
Coating(COATING)
CVD TiCN+Al2O3+TiN
Insert thickness(S)
0.25 in
Clearance angle major(AN)
0 °
Weight of item(WT)
0.0252 lb
Insert seat(SSC_M)
12
Insert seat size code imperial view(SSC_N)
1/2
Release date(ValFrom20)
24/09/2021
Release pack id(RELEASEPACK)
21.2
