570-3C 20 200
570-3C 20 200
Generic representation
Available
Package quantity: 1
ISO: 570-3C 20 200
Material Id: 5764551
EAN: 10698811
ANSI: 570-3C 20 200
Technical illustrations
Generic representation
Product data
Connection - machine side(ADINTMS)
Cylindrical shank without clamping features (without flange) -metric: 20.0
Connection - workpiece side
(ADINTWS)
SL (screw mounted) -straight -size 20, -slot coolant
Minimum overhang(OHN)
2.7559 inch
Maximum overhang
(OHX)
4.7244 inch
Hand
(HAND)
Neutral
Silent Tools™
(DPC)
Yes
Coolant entry style(CNSC)
axial concentric entry
Coolant exit style(CXSC)
axial inclined exit
Coolant entry thread size(CNT)
G 1/4-19
Coolant pressure(CP)
1,015.2642 lbf/in2
Location aid property(LOCAP)
Yes
Connection diameter machine side(DCONMS)
0.7874 inch
Connection diameter workpiece side(DCONWS)
0.7874 inch
Maximum allowed body temperature(TBX)
266 F
Max. Cutting force(FFCX)
287.7554 lbf
Functional length(LF_1)
7.874 inch
Functional width(WF_1)
0 inch
Functional height(HF_1)
0 inch
Body diameter(BD_1)
0.7874 inch
Body length(LB)
7.874 inch
Overall length(OAL)
7.874 inch
Torque(TQ)
2.0652 ftlbf
Body material
(BMC)
Steel
Weight of item(WT)
1.0243 lb
Release date(ValFrom20)
13/09/1993
Release pack id(RELEASEPACK)
93.3
